3 Kva Numeric Online UPS

Name: 3 Kva Numeric Online UPS
Brand: LAKSH POWER SOLUTION
Price: 50000.0 INR
Availability: InStock

Price 50000.0 INR/ Unit

Get a Price/Quote

MOQ : 10 Units

3 Kva Numeric Online UPS Specification

Product Type
Online UPS

Standard
Normal

Rated Voltage
230V AC

Frequency (MHz)
50 Hz

Protection
Overload, Short Circuit, Overtemperature, Surge Protection

Usage
Commercial

Size
Standard 3 Kva

Color
Black

Weight
18 kg

Dimension (L*W*H)
482 x 420 x 88 mm

Battery Backup Time
Depends on battery AH, typically 15-30 min with standard bank

Noise Level
< 50 dB at 1 Meter

Display
LCD Digital Display

Operating Temperature
0C to 40C

Output Voltage Regulation
+/- 1%

Efficiency
>= 90%

Humidity
0% - 95% RH Non-Condensing

Waveform
Pure Sinewave

Input Voltage Range
160V - 280V AC

Battery Type
External, Sealed Maintenance Free (SMF)

Communication Interface
RS232/USB

Phase
Single Phase Input & Output

Transfer Time
0 ms (True Online)

Capacity
3 Kva

3 Kva Numeric Online UPS Trade Information

Minimum Order Quantity
10 Units

Supply Ability
1000 Units Per Month

Delivery Time
10 Days

Main Domestic Market
All India

About 3 Kva Numeric Online UPS

We are providing a huge array of 3 Kva Numeric Online UPS. It is suited for workstations, security surveillance equipment, network accessories and so on. This range is completely isolates the attached equipment from the raw power line. It is easy to use and safe to maintain.

A 3 kVA Numeric Online UPS is a compact uninterrupted power supply system designed to provide continuous and clean power for sensitive electronic equipment. Manufactured by Numeric Power Systems, this UPS uses online double-conversion technology to protect connected devices from power failures, voltage fluctuations, surges, and electrical noise.

Description

The 3 kVA Numeric Online UPS continuously converts incoming AC power into DC and then back into regulated AC output. Since the inverter always powers the load, there is zero transfer time during power outages, ensuring uninterrupted operation of critical equipment.

Key Features

Capacity: 3 kVA
Technology: True Online Double Conversion
Input/Output: Single Phase
Output Waveform: Pure Sine Wave
Zero Transfer Time
Wide Input Voltage Range
Automatic Battery Charging
LCD/LED Display for Monitoring
Intelligent Battery Management
Generator Compatibility

Protection Features

Overload protection
Short-circuit protection
Battery deep discharge protection
Surge and spike protection
Over-temperature protection

Applications

Desktop computers and workstations
Small servers and networking devices
CCTV and security systems
Medical and laboratory equipment
Office automation systems
Retail billing systems

Advantages

Continuous power without interruption
Protects sensitive equipment from damage
Stable and regulated output voltage
Reliable backup during power failures
Compact and space-saving design

Exceptional Voltage Stability

With precise voltage regulation of 1%, this UPS consistently delivers stable power to protect sensitive electronics from harmful fluctuations. Its pure sinewave performance ensures the safe operation of modern devices requiring clean and unwavering current. The system is specifically engineered to meet commercial demands where reliability is critical.

Zero Downtime Power Protection

Featuring true online double conversion technology, this UPS ensures a seamless transition during power failures. With zero transfer time and external sealed maintenance-free batteries, it effectively eliminates interruptions, making it ideal for environments where uninterrupted operations are essential, such as data centers and offices.

User-Friendly Monitoring and Connectivity

An advanced LCD digital display provides clear, real-time insights into operating status and conditions, enabling proactive management. The UPS offers communication options via RS232 or USB, supporting integration with IT management systems for enhanced oversight and control.

FAQ's of 3 Kva Numeric Online UPS:

Q: How does the 3 Kva Numeric Online UPS maintain power stability during outages?

A: The 3 Kva Numeric Online UPS utilizes true online double conversion technology, which converts incoming AC power to DC and then back to AC, ensuring continuous and regulated power without transfer delay during outages. This mechanism provides seamless power to connected devices, protecting them from fluctuations and interruptions.

Q: What type of batteries are recommended for this UPS, and how long is the typical backup time?

A: External sealed maintenance-free (SMF) batteries are recommended for use with this UPS. Typical backup duration ranges from 15 to 30 minutes with a standard battery bank, but actual backup time depends on the capacity (AH) and size of the batteries selected.

Q: When should I consider using a 3 Kva Numeric Online UPS in my business?

A: You should consider this UPS when you require uninterrupted, stable power for critical commercial equipment, such as servers, network infrastructure, and sensitive laboratory devices. It's especially suitable for locations with frequent power fluctuations, outages, or environments where consistent uptime is necessary.

Q: Where can this UPS be installed for optimal performance?

A: Install the UPS in a well-ventilated, dust-free environment within the recommended temperature (0C to 40C) and humidity range (0%-95% RH, non-condensing). It is compact enough for standard server racks or commercial office setups, making it versatile for different business settings across India.

Q: What is the installation process for connecting external batteries to this UPS?

A: The installation involves securely connecting the external SMF batteries to the UPS battery terminals according to the specified voltage configuration. It's advisable to use a qualified technician or authorized service provider for safe and correct installation to ensure system reliability and to maintain warranty coverage.

Q: How does this UPS benefit commercial users?

A: Commercial users benefit from uninterrupted power, high efficiency (90%), and comprehensive protection features, including overload, short circuit, surge, and overtemperature protection. Its pure sinewave output ensures compatibility with all modern electronics, safeguarding valuable equipment and ensuring business continuity.

Q: What communication interfaces are available for remote monitoring and management?

A: The UPS provides RS232 and USB communication ports, allowing for remote monitoring and management through compatible software. This enables users to monitor performance, receive alerts, and manage power settings efficiently from a distance.
